Setra 217 Ultra High Purity Pressure Transducer

Request a Quote
close-link

Part Number: Setra 217 Categories: , Tags: , , , , ,
  • Free Shipping
    celectric logo

    Questions? Call +604-502 1894 Mon-Fri 8:30am to 5:30pm or Email [email protected]

    FREE Domestic AND SEA Shipping!

    Most orders RM500/USD120 or more ship SEA for FREE!

    • Delivery within the Southeast Asia only.
    • Hazardous items excluded.
    • Extremely heavy or bulky items excluded.
    • Distributors, Resellers and OEMs excluded.
    • Contact us for shipping charge for orders < RM500/USD120
    close-link
  • Free Technical Support
    celectric logo

    Questions? Call +604-502 1894 Mon-Fri 8:30am to 5:30pm

    Setup, Configuration and Technical Support of our Products are FREE.

    We help to check your faulty Instruments too, fill in the form here

    Free phone and email tech support continues as long as you own the product. Click here for contact information.

    close-link
  • Product Features

    • 316 L VIM/VAR stainless steel
    • Surface finish 7 Ra
    • VCR connector
    • 1×10-9 ATM.CC/sec level ammonia leakage test
    • Excellent stability and avoid downtime
    • Optional pressure port with C or W seal
    • Anti-electromagnetic interference / RF interference to prevent false stops
    • Easy to purge
    • Meet CE and RoHS standards
    • Optional UL 1604 and ATEX 94/9/EC Approval Available for 4 to 20mA Output Units

    Designed for modular “Block” gas bars and panels, the Setra Model 217 Pressure Transmitter is ideal for pressure measurement applications in harsh environments such as temperature transients caused by cold airflow.

    The Model 217 Pressure Transmitter can be fitted with a downwardly mounted pressure port with a Type C or W seal with a small sensor chamber that is easy to purge. All wetted parts are made of VIM/VAR 316L stainless steel and surface passivated to 5 Ra (up to 7 Ra) to ensure a smooth surface and chemical resistance for contamination-free gas delivery. Each sensor was subjected to a helium leak test of 1 x 10-9 ATM.CC/sec level using a mass spectrometer.

    All of Setra’s ultra-high-purity products are based on Setra’s proven capacitive sensing technology, which provides a highly accurate, stable voltage or current output signal that is virtually immune to EMI/RFI interference.

    • Low leakage rate
    • VCR connector
    • A small chamber that is easy to purge
    • 200PSI/250PSI/3000PSI

    Characteristic

    • 316 L VIM/VAR stainless steel
    • Surface finish 7 Ra
    • VCR connector
    • 1×10-9 ATM.CC/sec level ammonia leakage test
    • Excellent stability and avoid downtime
    • Optional pressure port with C or W seal
    • Anti-electromagnetic interference / RF interference to prevent accidental downtime
    • Easy to purge
    • Meets CE and RoHS standards

    Applications

    • Modular “Block” gas bars and panels
    • High purity gas delivery system
    • Semiconductor process tools

    Data Sheet: Setra Model 217 Data Sheet

    User Manual: Setra Model 217 Operating Instructions
