Gems Sensors & Controls FS-480 Series Flow Switch

Last Updates: 15/08/2020

Gems Sensors & Controls 204711

$521

Lead Time: 4 to 6 weeks

Part Number: 204711 Categories: ,

Email Us: sales@celectric.com.my
WhatsApp Us: +60165519084

skuFS-480
Primary Material of ConstructionAlloy
Sensor TypePiston Type
Adjustable RangeN/A
Flow Setting (GPM)1.00
Body Material316 Stainless Steel
Port Size1/2″ Tube Compression
Switch TypeSPST, N.O. (20VA)
Set Point Accuracy±20%
Maximum Pressure (PSI)Over 500
Minimum Temperature (°F)-20
Maximum Temperature250
Electrical Termination22 AWG, 24″-26″ long PVC Cable
Set Point Differential20%
Wetted Materials316 Stainless Steel, PPS, Epoxy, Fluorocarbon
ApprovalsUL Recognized
Recommended Filtration100 micron



The FS-480 large-body inline flow switch delivers ample flow rates with minimal pressure drop. 25% larger than its FS-380 sibling, the FS-480 is ideal for processes that push more fluid through their systems and demand low pressure drops. Designed to accommodate the Semiconductor Industry’s move to larger 300 mm wafer and cross-over equipment, this switch is also perfect for critical medical equipment applications. A glass-reinforced PPS piston and forged 316 stainless steel body make this sensor rugged enough for high pressure lubrication and cooling systems as well. This simple, yet meticulously perfected design provides the reliability required in critical applications while allowing for much lower pressure drop rates than other available switches.
