Gems 244551

Actuation Level N/A
Switch Operation Wet Source
Min. Liquid N/A
Stem Material Stainless Steel
Float Material N/A
Float Diameter N/A
Mounting Size 1/2″-14 NPT
Mounting Vertical or Horizontal
Switch Type Open Collector sourcing output, 9-32 VDC, 30 ma max
Input 9-32 VDC
Output Current Sourcing, 9-32 VDC, 30 ma max
Maximum Pressure (PSI) 100
Minimum Temperature (°F) -40
Maximum Temperature (°F) 257
Electrical Termination 36″ PVC Cable
Wetted Materials Stainless Steel, EPDM, Versaplast
Approvals CE, IP67, RoHS,

Data Sheet:Gems_CAP300-Datasheet
Instruction Manual: Gems_CAP-300_Manual
