Actuation Level N/A
Switch Operation Wet Sink
Min. Liquid N/A
Stem Material Brass
Float Material N/A
Float Diameter N/A
Mounting Size M12x1.5 Stud End Per ISO6149-3
Mounting Vertical or Horizontal
Switch Type Open Collector sinking output, 9-32 VDC, 30 ma max
Input 9-32 VDC
Output Current Sinking . 9-32 VDC, 30 ma max
Maximum Pressure (PSI) 100
Minimum Temperature (°F) -40
Maximum Temperature (°F) 257
Electrical Termination 12″ 18 AWG SXL Flying Leads
Wetted Materials Brass. EPDM, Versaplast
Approvals CE, IP67, RoHS,
