Dwyer Series 1620 Single and Dual Pressure Switch

Request a Quote
close-link

Part Number: Series 1620 Categories: ,
  • Free Shipping
    celectric logo

    Questions? Call +604-502 1894 Mon-Fri 8:30am to 5:30pm or Email [email protected]

    FREE Domestic AND SEA Shipping!

    Most orders RM500/USD120 or more ship SEA for FREE!

    • Delivery within the Southeast Asia only.
    • Hazardous items excluded.
    • Extremely heavy or bulky items excluded.
    • Distributors, Resellers and OEMs excluded.
    • Contact us for shipping charge for orders < RM500/USD120
    close-link
  • Free Technical Support
    celectric logo

    Questions? Call +604-502 1894 Mon-Fri 8:30am to 5:30pm

    Setup, Configuration and Technical Support of our Products are FREE.

    We help to check your faulty Instruments too, fill in the form here

    Free phone and email tech support continues as long as you own the product. Click here for contact information.

    close-link
  • On the Series 1620 Single and Dual Pressure Switch, our old faithful switch design is still best where highest precision combined with diaphragm sealed leak proof construction and mounting simplicity are required. Model 1626 and 1627 differential pressure switches are identical in design and construction except that Model 1626 has a single electric switch and Model 1627 has dual electric switches. Model 1627 can therefore provide dual control when required. It can be set to open or close two independent electrical circuits, each preset for its own actuation pressure. Both units have diaphragm sealed motion take outs providing maximum protection against leakage.

    CAUTION: FOR USE ONLY WITH AIR OR COMPATIBLE GASES.

    Product Applications

    • Damper positioning
    • Duct air contro

    Service : Air and non-combustible, compatible gases.

    Wetted Materials : Consult factory.

    Temperature Limits : -30 to 130°F (-34.4 to 54.4°C).

    Pressure Limits : Max. 50 in. w.c. (12.44 kPa) continuous, 2 psig (13.79 kPa) surge.

    Switch Type : 1626: SPDT; 1627: (2) SPDT.Repeatability:±1%.

    Electrical Rating : 15 A @ 120 to 480 VAC, 60 Hz. Resistive, 1/8 HP @ 125 VAC, 1/4 HP @ 250 VAC, 60 Hz.

    Electrical Connections : 3 screw type, common, normally open and normally closed.

    Process Connections : 1/8″ female NPT.

    Mounting Orientation : Diaphragm in vertical position. Consult factory for other position orientations.

    Set Point Adjustment : Screw adjustment.

    Weight : Model 1626: 3 lb 9.8 oz (1.64 kg); Model 1627: 3 lb 11.8 oz (1.69 kg).

    Agency Approvals : CE.

    • Single or dual action switches support consistent designs with similar models, but with the ability to match specific application needs
    • Sealed diaphragm provides leak-proof construction for high accuracy and precision control

    Product Literature

    Manual

    Catalog Page
