Dwyer 1221/1222/1223 Flex-TubeĀ® U-Tube Manometer

SKU: 1221/1222/1223

Better Precision U-Tube Manometer, suitable for Pressures up to 100 psiĀ

Category: Pressure Gauges

Price on request

Send us your requirement and we'll reply with a quotation and technical advice.

ā± We reply within 1 working day. Specs & downloads ↓
šŸ› ļø
Lifetime technical support
🚚
Free domestic shipping
šŸŽÆ
Calibration services

Follow Celectric's WhatsApp Channel →

Product details

Dwyer Series 1221/1222/1223 is inexpensive manometers measure positive, negative, and differential pressures. Dwyer Flex-TubeĀ® U-Tube Manometers combine the inherent accuracy of the simple “U” Tube with the durability of tough, long-lasting plastic construction. Columns are of .375″ O.D. flexible and shatterproof clear butyrate tubing. They are easily accessible for cleaning. The indicating tube is backed by a white scale channel to provide maximum color contrast. Scales are extruded high-impact polystyrene plastic, formed to hold columns in perfect alignment. Stark white scales have graduations and numbers silkscreen-printed in black for maximum legibility.

Numerous models selection and features including over-pressure safety traps, in full scale ranges from 8″ to 36″ of water or mercury. All are suitable for total pressures to 100 psi – for determining velocity and static pressures, leakage, fan and blower efficiency, filter resistance, and gas pressures. Ideal wherever a portable, direct reading manometer is needed. Standard ranges and markings as shown or special ranges, colors, logos, and brand names for OEM quantity orders are available.

Product Applications

  • Duct static pressure
  • Calibration labs
  • Filter monitoring
  • Combines the inherent accuracy of a U-tube manometer with durable plastic construction
  • High-contrast scale improves reading precision
  • Series 1221 is the simplest, lowest-cost basic U-gage
  • Series 1222 adds magnetic mounting clips and a clamp bar to prevent tube slipping
  • Series 1223 is the top-tier model with safety traps that guard against fluid loss from accidental overpressure
  • Optional NIST-traceable calibration certificate (-NIST suffix)
Pressure RangeSuitable for total pressures up to 100 psi; scale ranges 8-36 in w.c. or 200-1000mm w.c., by model
Vacuum LimitNot recommended above 5in Hg (68in w.c.)
Process Connection1223: rapid shut-off molded nylon with 1/8″ adapters; 1221/1222: flexible tubing connectors for 3/16″ tubing
MaterialsClear butyrate tubing (0.375″ OD), white scale channel; 1223 adds high-impact acrylic top and Tygon tubing
Indicating FluidWater, mercury, or red gage fluid (0.826 SG)

Which model should I choose for a permanent vertical installation?
Series 1222 or 1223 — both add magnetic mounting clips for steel surfaces, with 1223 also adding safety traps against overpressure fluid loss.

Is this manometer suited to vacuum service?
It’s not recommended for vacuum above 5in Hg (68in w.c.); for deeper vacuum, a different gauge style would be more suitable.

What applications is this manometer family typically used for?
Duct static pressure checks, calibration lab reference readings, and filter monitoring.

Download Dwyer 1221/1222/1223 Flex-TubeĀ® U-Tube Manometer information here

Datasheet: Dwyer_Series-1221-1222-1223_Catalog
Manual: Dwyer_1221-1222-1223_Manual
