Yokogawa CA300 Series Process Calibrator

Last Updates: 25/10/2020
Brands:Yokogawa

Yokogawa CA330 RTD Calibrator

  • Basic accuracy: 0.3°C
    (Typical of PT100)
  • Corresponds to 14 types of RTD standard
    (JIS/IEC/GOST R)
  • Sub display displays value of resistance source and span%
  • Corresponds to various types of source pattern
    (Step sweep/ Linear sweep/ Manual step/ Span check)
  • Corresponds to 2,3,4 wire. Realizes RTD simulation
  • Measures output of RTD sensor as a thermometer

RTD SIMULATE

CA330 corresponds to 14 types of RTD for sourcing. It achieves a high basic accuracy of 0.3°C (typical of type PT100), twice better than the previous model which enables it to operate a highly reliable test.

RTD MEASURING

CA330 can measure the output of RTD like a thermometer. It achieves the basic accuracy of 0.3°C (typical of type PT100), twice better than the previous model and is for multiple use of process temperature measuring by corresponding to 14 types of RTD.

Addition of Sub Display

The sub-display additionally shows span%, source value of voltage, or resistance, while the main display shows the setting value.

Catalog: Yokogawa CA300 Bulletin
Instruction Manual: Yokogawa CA300 Series Manual
CA310 Instruction Manual: Yokogawa CA310 Manual
CA320 Instruction Manual: Yokogawa CA320 Manual
CA330 Instruction Manual: Yokogawa CA330 Manual
