|Switch Operation||Normally Closed (Reversible)|
|Mounting Size||1/8″ NPT Male|
|Switch Type||SPST (20 VA)|
|Maximum Pressure (PSI)||50|
|Minimum Temperature (°F)||-40|
|Maximum Temperature (°F)||180|
|Electrical Termination||22 AWG, 24″ long PVC leads|
|Wetted Materials||Polysulfone, buna N, Epoxy|
The durable construction of these reed switch designs ensures long, trouble-free service. Because the effects of shock, wear and vibration are minimized, these hermetically sealed level switches provide precise repeatability with no more than 1% deviation. The level switch actuation points remain constant over the life of the unit.
Ideal for shallow tanks or restricted spaces, or for any low-cost, high volume use. LS-3 Series are available in FDA/NSF compliant materials upon request, consult Gems™ for details.
NEW LS-3 MICRO: Gems’ newest addition to the LS-3 series family is the LS-3 Micro. It is the smallest LS-3 series switch available. These units are ideal for potable water, medical devices and other compact appliances such as printers. Gems LS-3 Micro float enables use in lighter-than-water fluids. These switches are also made with FDA compliant material, which expands the scope in which these floats can be used.
